Scope of application
LRS-YG series is suitable for identification of ground lead or other parts required of identification.
Product features
shrinking Ratio2: 1
flexible product, high convenience
temperature range: -55ºC~135ºC
complete shrinkage temperature 110ºC
flame retardant property: VW-1
Standard color: yellow-green
Main performance
| Item |
Test condition |
Typical test data |
|
tensile strength |
ASTM D 638 |
14Mpa |
|
elongation at break |
ASTM D 638 |
400% |
|
volume resistivity |
ASTM D 876 |
2 ×1014 Ω.cm |
|
water absorption |
ASTM D 570 |
0.2% |
|
after aging tensile strength(175ºC 168 hours) |
ASTM D 638 |
12Mpa |
|
after aging elongation at break(175ºC 168 hours) |
ASTM D 638 |
350% |
|
disruptive strength |
ASTM D 150 |
23 KV/mm |
|
thermal shock resistance (250ºC 4 hours) |
ASTM D 2671 |
up to standard |
|
low-temperature bend test (-55ºC 4 hours) |
ASTM D 2671 |
up to standard |
|
eccentricity |
UL224 |
15% |
|
longitudinal shrinkage ratio |
UL224 |
-1% |
LRS-YG series specification
| No. |
Specification |
After shrinkageinner diameter |
After shrinkageWall thickness |
Before shrinkageinner diameter |
Before shrinkageWall thickness |
Length of the packing |
|
LHS-YG/0030 |
3.0/1.5 |
1.4±0.1 |
0.45±0.05 |
3.4±0.3 |
0.20±0.05 |
200 |
|
LHS-YG/0060 |
6.0/3.0 |
2.8±0.1 |
0.45±0.05 |
6.4±0.3 |
0.20±0.05 |
100 |
|
LHS-YG/0080 |
8.0/4.0 |
3.8±0.2 |
0.55±0.05 |
8.4±0.4 |
0.35±0.05 |
100 |
|
LHS-YG/0100 |
10.0/5.0 |
4.8±0.2 |
0.60±0.05 |
10.5±0.4 |
0.35±0.05 |
100 |
|
LHS-YG/0120 |
12.0/6.0 |
5.7±0.3 |
0.75±0.05 |
12.5±0.4 |
0.35±0.10 |
100 |
|
LHS-YG/0150 |
15.0/7.5 |
7.2±0.3 |
0.80±0.05 |
15.5±0.5 |
0.40±0.10 |
100 |
|
LHS-YG/0200 |
20.0/10.0 |
9.7±0.3 |
0.95±0.05 |
21.0±0.5 |
0.50±0.10 |
100 |
|
LHS-YG/0250 |
25.0/12.5 |
11.5±0.5 |
0.95±0.05 |
25.8±0.8 |
0.50±0.10 |
25 |
|
LHS-YG/0300 |
30.0/15.0 |
14.5±0.5 |
0.95±0.05 |
30.8±0.8 |
0.50±0.10 |
25 |
|
LHS-YG/0400 |
40.0/20.0 |
19.5±0.5 |
1.00±0.05 |
41.0±1.0 |
0.50±0.10 |
25 |
|
LHS-YG/0500 |
50.0/25.0 |
24.5±0.5 |
1.00±0.05 |
51.0±1.0 |
0.50±0.10 |
25 |
|
Standard color: yellow-green |
||||||
